SunX™ Reflect - Reflective glass with solar control

SunX™ Reflect - Reflective glass with solar control

SunX™ Reflect Low E - double glazing

Glass with an elegant, reflective appearance for privacy - plus the benefit of solar control

  • New from Metro Glass, SunX™ Reflect Low E has replaced Stopsol Classic

  • SunX™ Reflect has a beautiful, reflective exterior appearance - perfect for creating privacy

  • Up to 61% better heat retention than standard double glazing

  • Reduces solar heat by up to 71%* compared to standard double glazing, great for homes in warmer regions with a lot of sunshine

  • The reflective exterior not only provides privacy, but helps protect you from the sun’s glare, letting in 31% of visual light.

  • H1 compliant across all zones (subject to spacer width)

Note: our double glazing range can be combined with laminate or obscured glass for improved acoustic or UV protection. Whatever your requirements are, we can tailor a solution for your home.

View Gallery

SunX Reflect Low E double glazing - performance data

Make-up mm

Heat Loss

Visibility

Heat Gain



Fading

Ug

U Value
Insulation value,
lower is better

VLT

Visible Light Transmission
Higher % means
more daylight
transmitted

VLR-E

External Reflectance
Higher % means
more reflection seen

SF

Solar Factor (g)
Lower number
means less solar
heat coming in

LSG

Selectivity
Higher number
means more light and less solar heat

Tdw-ISO

Damaged
Weighted Transmission
Lower value means better
fading
protection

4-8-4

1.7

31%

45%

22%

1.41

0.27

4-10-4

1.4

31%

45%

22%

1.41

0.27

4-12-4

1.3

31%

45%

22%

1.41

0.27

4-14-4

1.1

31%

45%

22%

1.41

0.27

4-16-4

1.1

31%

45%

22%

1.41

0.27

4-18-4

1.1

31%

45%

22%

1.41

0.27

View technical data for our double glazing range here.

Technical Brochure

Compare performance

Compare the performance of our Low E double glazing range - Xcel™, Xtreme™, SunX™ Grey and SunX™ Reflect vs standard double glazing.

Performance Table

Warranty & glass care

To register a warranty or find out more about the warranties we offer.

Warranties

For handling, care and maintenance information.

Glass Care & Maintenance

SunX™ Reflect Performance

SunX™ Reflect Low E Double Glazing units have argon filled thermal spacers. The data shown is based on a make-up of 4-14-4.

U-value (based on 4-14-4)

1.1

Visible Light Transmission (VLT)

31%

Solar Factor (SF)

22%

Fading Protection (Tdw-ISO)

0.27

Compare Performance

To help you select the right double glazing glass, this table helps you assess the performance of our Low E range, compared to standard double glazing.

U VALUE (MAKE-UP OF 4-14-4)

Insulation value, lower is better

SOLAR FACTOR (SF)

Lower means less solar heat

VISUAL LIGHT TRANSMISSION (VLT)

Higher means more natural light

FADING PROTECTION (TDW-ISO)

Lower means better fading protection

COLOUR HUE

Spacious glass sliding doors opening to a panoramic hillside vista
Standard Double Glazing
2.8
77%
82%
0.74
Clear
Modern grey bedroom boasting ceiling-to-floor windows overlooking serene bushland
Xcel™ Low E
1.1
59%
80%
0.69
Clear
Inviting modern room with expansive glass corner opening to a lush outdoor setting
Xtreme™ Low E
1.1
40%
74%
0.58
Neutral tone
Spacious and breezy conservatory with ocean vistas and a white seating arrangement
SunX™ Grey Low E
1.1
24%
41%
0.32
Grey tone
SunX™ Reflect Low E
1.1
22%
31%
0.27
Reflective silver
Double glazed glass panels stacked on white surface

Need more options?

Our double glazing range can be combined with laminate, tinted or obscured glass. Whatever your requirements are, we can tailor a solution for your home.
